15
Cleanup - Cleaning the Spray Gun Components
1. Make sure the pump is switched OFF (O). Make
sure the PRIME/SPRAY knob is turned to PRIME.
Unplug the sprayer.
2. Remove spray gun from the paint hose using adjustable
wrenches
3. Remove lter from spray gun (refer to Cleaning the
Spray Gun Filter,
5. Install gun lter tapered-end rst. Reassemble spray
gun.
7. Thread the spray gun back onto the paint hose.
Tighten with a wrench.
6. Install spray p (a), saddle seat (c) and washer (b),
and replace spray guard assembly.
4. Remove spray p (a) from spray guard assembly. Clean
spray p with a so-bristled brush and the appropriate
cleaning soluon. Be sure to remove and clean the washer
(b) and saddle seat (c) located in the rear of the spray guard
assembly.
(b)
(b)
(c)
(c)
(a)
(a)
