ED01_REV01-2020 IFU OB2012-2P_ENG
4 - 36
0. MEANING OF SYMBOLS AND PICTOGRAMS
0.1. Symbols used in these operating instructions to call the reader’s attention
Danger: important safety-related information covering correct use of the suction unit to prevent
operator or patient injury and/or damage to unit itself
Warnings: information requiring special attention
Notes or information on preventing damage to the device or injury to others. Implement correct
prevention measures
1.
List of actions to be performed: follow them step by step
These operating instructions
Electric and magnetic fields generated by radiographic or tomographic equipment, portable
radio equipment, RF radios and devices bearing this symbol could have an impact on proper
operation of the suction unit. In these cases, suction units must not be used, or must be kept at
a suitable distance from such equipment
Suction units OB 2012 contain electrical or electronic parts that must be recycled in accordance
with WEEE/19/EU - Waste Electrical and Electronic Equipment.
The suction unit complies with European Directive 2011/65/EU (RoHS)
Maintenance service required (contact the manufacturer and/or its authorized service centres)
0.2. Symbols used on the device and accessories
Class II insulation (as per IEC 60601-1)
Class BF for part applied to the patient (as per IEC 60601-1)
Use the suction unit only within the specified temperature range. Using the suction unit outside
these limits could compromise its operation, reduce battery life and trip the internal safety
devices.
Usage range for atmospheric pressure (from 70 kPa to 110 kPa)
Usage range for humidity (from 15% to 95%)
Read these operating instructions carefully and thoroughly
Accessories and/or consumables displaying this symbol are disposable. They cannot be reused
and, after use, must be discarded and replaced with new ones. The symbol is posted on
consumables
