Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
Chuck Tap
Capacities Capacities
1/8
" - 3/8" 5/32" - 3/8"
NOTE: For tool specifications refer to the nameplate on your tool.
TRIGGER
MOTOR
HOUSING
Tapper
AIR
VENTS
FIG. 1
“LOCK-ON”
BUTTON
PRESET
SPEED ADJUSTING
DIAL
AIR
VENTS
CHUCK
SCREW
