Bosch 8733951039 - 12 ZS Series Zone Sensor R1 Dimensions; 13 Compatible Controllers

Installation & Operation Manual Bosch ZS Series Zone Sensors R1 | 17
Bosch Thermotechnology Corp. | 02 .2018
Data subject to change
12 ZS Series Zone Sensor R1 Dimensions
Figure 12
2.75"
(same for all)
4.75"
(same for all)
0.80"
13 Compatible Controllers
Figure 13
Control Air 5600 Control Air 6120Control Air 5830
