English–1
Bosch eBike Systems 1 270 020 XBI | (11.4.16)
Safety Notes
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Save all safety warnings and instructions for future
reference.
The term “battery pack” used in these operating instructions,
irrespective of model, refers both to standard battery packs
(battery packs with holder on the bike frame) and to rack-type
battery packs (battery packs with holder in the rear rack/
carrier).
f Do not use the on-board computer as a handle. Lifting
the eBike up by the on-board computer can cause irrepara-
ble damage to the on-board computer.
f Make sure to not be distracted by the display of the
on-board computer. If you do not focus exclusively on
the traffic, you risk being involved in an accident. If you
want to make entries in your on-board computer other
than switching the assistance level, stop and enter the
appropriate data.
f Read and observe the safety warnings and instructions
in all operating instructions of the eBike system and in
the operating instructions of your eBike.
Product Description and
Specifications
Intended Use
The Intuvia on-board computer is designed to control Bosch
eBike systems and display riding data.
Product Features
The numbering of the components shown refers to the illus-
trations on the graphic pages at the beginning of the manual.
Individual illustrations in these operating instructions may dif-
fer slightly from the actual circumstances depending on the
equipment of your eBike.
1 Display-function button “i”
2 Bike lights button
3 On-board computer
4 Holder for on-board computer
5 On/Off button for on-board computer
6 “RESET” button
7 USB port
8 Protective cap of USB port
9 Operating unit
10 Display-function button “i” on the operating unit
11 Decrease assistance level/scroll down button “–”
12 Increase assistance level/scroll up button “+”
13 Push-assistance button “WALK”
14 Lock latch for on-board computer
15 Locking screw for on-board computer
USB charging cable (Micro A – Micro B)*
* not illustrated; available as accessory
Display elements of on-board computer
a Drive unit assistance indicator
b Assistance-level indicator
c Light indicator
d Text indication
e Value indication
f Speed indication
g Shift recommendation: higher gear
h Shift recommendation: lower gear
i Battery charge-control indicator
Technical Data
Assembly
Inserting and removing the battery pack
For inserting and removing the eBike battery pack in/from the
eBike, please read and observe the battery pack operating in-
structions.
Inserting and removing the on-board computer
(see figure A)
To insert the on-board computer 3, slide it from the front into
the holder 4.
To remove the on-board computer 3, press the lock latch 14
and slide the on-board computer toward the front out of the
holder 4.
On-board computer Intuvia
Article number
1 270 020 906/909
Max. charging current,
USB connection
mA 500
Charging voltage,
USB connection
V 5
USB charging cable
1)
1 270 016 360
Operating temperature
°C –5...+40
Storage temperature
°C –10...+50
Charging temperature
°C 0...+40
Internal lithium-ion battery
V
mAh
3.7
240
Protection type
2)
IP 54 (dust and splash
water protected)
Weight, approx.
kg 0.15
1) Not included in standard scope of delivery
2) When USB cover is closed
Bosch eBike system uses FreeRTOS (see www.freertos.org)
OBJ_BUCH-2795-001.book Page 1 Monday, April 11, 2016 4:27 PM
