English – 35
Bosch eBike Systems 1 270 020 Wen | (13.5.16)
To increase the assistance level, press the “+” 14 button on the operat-
ing unit until the desired assistance level appears in the display r5. To
decrease the assistance level, press the button “ – ” 13.
The requested motor output is displayed in indicator r4. The maximum
motor output depends on the selected assistance level.

When the on-board computer is removed from the holder 4, the last indi-
cated assistance level is stored; the motor-output indicator r4 remains
empty.
Assistance Level Assistance Factor * (Derailleur)
Active Line Performance Line
Cruise Cruise Speed CX
“ECO”
40 % 50 % 55 % 50 %
“TOUR”
100 % 120 % 120 % 120 %
“SPORT”
150 % 190 % 190 % 210 %
“TURBO”
250 % 275 % 275 % 300 %
* The motor output can vary for individual versions.
