Quick Start Guide|
ADS 625X for ADAS
1699504264 | VER 01 | 06.2022
© Bosch Automotive Service Solutions Inc
General Information
Introduction
1. Vehicle connection
indicator
2. VCI connection manager
3. Power button
4. Volume up button
5. Volume down button
6. Front facing camera
7. Ambient light sensor
8. USB C charging/data port
9. Main Menu functions
10. SD card access door
11. Back button
12. Home button
13. Recent app button
14. Docking station connector
TOP VIEW
BOTTOM VIEW
Connected
10:22
Main Menu
ADAS Calibration
Pre/Post Scan
Settings
What’s New
Web Browser
Vehicle Diagnostics Repair Source Generic OBD II
Saved ADAS
Reports
Apps Shortcut
Video Tutorials
6 7
1
2
13
12
1114 10
9
3
4 5
8
