Bosch C70 charger I Operating instructions EN
12
1 Charger
2 Mounting hook
3 Mains cable with mains connection
4
Charging cable
a Plug
5
Charging cable with clip
a Plug
6 (+) Terminal clamp (red)
7 (–) Terminal clamp (black)
8 Standby
9 Mode selection button
10 Reverse polarity protection + -
11 Battery capacity indicator
Battery capacity: 100%
Battery capacity: 75%
Battery capacity: 50%
Battery capacity: 25%
12 Mode 1 | 12 V
(motorcycle/car)
13 Mode 2 | 12 V (charging at
0-4°C in winter or AGM)
14 Mode 3 | 12 V (maintenance)
15 Mode 4 | 12 V (regeneration)
16 Mode 5 | 12 V (voltage main-
tenance during battery
change)
17 Mode 6 | 24 V (truck)
18 Mode 7 | 24 V (charging at
0-4°C in winter or AGM)
Device description
(9)
(8)
(15) (12)
(17)
(11)
(13)
(18)
(14)
(16)
(10)
(1)
(5)
(6)
(5a)
(4)
(7)
(3)
(2)
(5a)
(5a)
(4a)
