Coach Power Amplifier
CPA 811 / CPA 2011
Operating voltage: + 24 V
Current consumption:
Standby: < 500 �A incl. CCD
and CCS
Max. CPA 811: Approx. 10 A incl.
CCD and CCS
Max. CPA 2011: Approx. 15 A incl.
CCD and CCS*
* I max. without peripheral devices
Rated power output
Cockpit: 2 x 20 W / = 4 ohms
Cabin (CPA 811): 2 x 20 W / = 4 ohms
Cabin (CPA 2011): 4 x 40 W / = 4 ohms
Frequency response:
40 Hz - 25,000 Hz
Inputs, EXTERNAL (only cockpit)
CPA 811: WARNER 2 V,
NAVIGATION 2 V
CPA 2011: 2 V
All EXTERNALswitching inputs :
Active low
Voltage outputs:
24 V / 0.4 A max.
MIC: 24 V / 1.3 A max.
VIDEO 1, 2: 24 V / 0.4 A max.
Further inputs/outputs:
Line out, regulated
Weight:
CPA 811: Approx. 1.8 kg
CPA 2011: Approx. 1.9 kg
Subject to changes.
Technical data
