Bosch Climate 5000 AA Series Split Type Ductless Air Conditioner / Heat Pump Installation Manual
01.2017 | Bosch Thermotechnology Corp.Data subject to change
Step 4: Connect pipes
When connecting refrigerant pipes, be careful not to use excessive torque or to
deform the piping in any way. You should fi rst connect the low-pressure (suction)
pipe, then the high-pressure pipe (liquid line).
Minimum Bend Radius
When bending connective refrigerant piping, the minimum bending radius
is 10cm (4in). See Fig 32.
≥10cm (4in)Radius
Figure 32
