Bosch CLL5000 W 34 E - Page 21

21
Climate Line 5000 – 6721831678 (2021/02)
1
2
13
3
14
4
5
A [mm] B [mm] C [mm]
CLL5000 W 22 E 729 292 200
CLL5000 W 28 E 729 292 200
CLL5000 W 34 E 729 292 200
i
0010037339-001
5
2
3
4
1
7
8
9
6
0010032598-001
≥1800
≥150
≥120
≥120
C
C
BB
A
A [mm] B [mm] C [mm] D [mm] E [mm] F [mm]
CLL5000 22 E 790 720 452 270 495 255
CLL5000 28 E 790 720 452 270 495 255
CLL5000 34 E 790 720 452 270 495 255
≥300
C
D
E
≥600
≥300
≥2000
B
A
≥600
0010032599-003
F
≥ 250
H
≥ 3000
A
L ≤ ½H
→
→
L ≤ H
A ≥ 250
A ≥ 300
L > H
≥ 600
≥ 1500
L
0010033858-002
3
1 2
≤ 6 m
≤ 6 m
0010034026-001
