Appliance door en
33
Refitting the appliance door
Follow the instructions in the reverse order to refit the
appliance door.
1. Press down on the seal ‚ along the drip trough
(fig. !); otherwise, the seal ‚ may become detached
during cleaning.
2. When fitting the appliance door, ensure that both
hinges are inserted straight into the opening (fig.
").
Slide the appliance door down as far as it will go.
3. Open the appliance door fully. Close the two locking
levers (fig. #).
4. Close the cooking compartment door.
Removing and installing the door panels
To facilitate cleaning, you can remove the glass panels
from the appliance door.
Locking the appliance door
1. Open the appliance door fully.
2. Open the two locking levers on the left and right
(fig. !).
3. Close the appliance door as far as it goes (fig. ").
Removing panels
1. Press on the left- and right-hand sides of the cover
(fig.°!).
2. Remove the cover (fig. ").
3. Lift out the inner panel (fig. #) and set it down
carefully on a flat surface.
4. Take off the seal on both sides and remove it
(fig. $).
5. Lift out the intermediate glass panel (fig. %) and set
it down carefully on a flat surface.
6. If necessary, you can remove the condensate trough
for cleaning. To do this, open the appliance door
fully (fig. &).
7. Tilt the condensate trough up and remove it (fig. ').
1
2
2
1
2
1
