and installation manual for the specific control panel
and refer to the current rating chart for standby
battery calculations.
Wiring Considerations
Use 1.2 mm (18 AWG) or 0.8 mm (22 AWG) wire. Each
D1265 keypad includes a four position terminal strip
located on the backplate for easy removal.
Parts included
Quant. Component
1 Keypad
1 Literature
• Quick Installation Guide
• Literature CD
Technical specifications
Electrical Requirements
Voltage: 12 VDC nominal
Wire Length 1000 ft of 18 awg
Standby Current: Idle 135 mA
Maximum 300 mA, with the
sounder and display backlight at
maximum
Environmental Requirements
Environment: Indoor, dry
Relative Humidity: 90% at +50°C (+122°F)
Temperature (operating): -10°C to +60°C
(+14°F to +140°F)
Mechanical Properties
Color (enclosure): White
Dimensions: 119 mm x 122 mm x 29 mm
(4.7 in. x .4.8 in. x 1.2 in.)
Weight (Keypad): 0.24 kg (0.55 lb)
Number of
Keypads per control panel
GV4 Series, v8.11 or higher: Supervised: 16
Unsupervised: 32
GV3 Series, lower than v8.10
and GV2 Series:
Supervised: 8 Unsupervised: 32
Ordering information
D1265 Touch Screen Keypad
Touch screen keypad for use with GV4, GV3, and GV2
control panels
Order number D1265
2 | D1265 Touch Screen Keypad
