Model number DH712VC
Shank style SDS Max®
Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive
safety measures reduce the risk of starting the tool accidentally.
Demolition Hammer
NOTE: For tool specifications refer to the nameplate on your tool.
LOCKING
SLEEVE
DUST
SHIELD
LOCK KNOB
AUXILIARY
HANDLE
TRIGGER
SWITCH
TRIGGER
RELEASE
SWITCH
VARIABLE
SPEED DIAL
SERVICE
REMINDER
LIGHT
SELECTOR DIAL
DEMO HAMMER / VARIO-LOCK OPERATION
FIG. 1
VIBRATION DAMPER
HANDLE / HAMMER
MECHANISM
VENTILATION
OPENINGS
