14 | English
(1)
On/off switch
(2)
Speed preselection thumbwheel
(AdvancedCut50)
(3)
Base plate
(4)
Handle (insulated gripping surface)
(5)
Auxiliary handle (insulated gripping surface)
(6)
Locking lever of the saw blade receptacle cover
(7)
Cover of the saw blade receptacle
(8)
Saw blade
(9)
0° cut mark
(10) Viewing window for CutControl
(11) 45° cut mark (AdvancedCut50)
(12) Base forCutControl
(13)
Extraction outlet
(14)
Wing bolt for mitre/bevel angle setting
(AdvancedCut50)
(15) Scale for mitre/bevel angles (AdvancedCut50)
(16)
Saw blade receptacle
(17)
Anti-splinter guard
(18)
Depth stop A
a)b)
(19)
Depth stop B
a)b)
(20)
Hood for dust extraction
(21)
Saw blade storage compartment in the guide rail ad-
apter
a)
(22)
Guide rail adapter
a)
(23)
Locking lever for guide rail adapter
a)
(24)
Guide rail
a)
a)
Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
b)
Included in standard delivery with AdvancedCut50.
Technical Data
All-purpose saw EasyCut50 AdvancedCut50
Article number
3603CC80.. 3603CC81..
CutControl
● ●
Speed control ● ●
Speed preselection – ●
Rated power input W 500 500
Power output W 370 370
Max. cutting depth
A)
– Without depth stop mm 50 50
– With depth stop A mm 36 36
– With depth stop B mm 22 22
– With depth stop A and B mm 6 6
Max. mitre/bevel angle (right) ° 45 45
Weight according to EPTA-Procedure01:2014 kg 1.6 1.7
Protection class
/II /II
A) The resulting cutting depth is dependent on the saw blade used. The values stated here relate to the NanoBlade Wood Basic supplied.
The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models.
Noise/Vibration Information
Noise emission values determined according to
EN62841‑2‑11.
Typically, the A-weighted noise level of the power tool is:
Sound pressure level 86dB(A); sound power level
97dB(A). Uncertainty K=5dB.
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN62841‑2‑11:
Cutting boards with saw bladeNanoBlade Wood Basic50:
a
h,B
=2.5m/s
2
, K=1.5m/s
2
.
The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure and may be used to com-
pare power tools. They may also be used for a preliminary
estimation of vibration and noise emissions.
The stated vibration level and noise emission value repres-
ent the main applications of the power tool. However, if the
power tool is used for other applications, with different ap-
plication tools or is poorly maintained, the vibration level
and noise emission value may differ. This may significantly
increase the vibration and noise emissions over the total
working period.
To estimate vibration and noise emissions accurately, the
times when the tool is switched off or when it is running but
not actually being used should also be taken into account.
1 609 92A 65Z | (25.11.2020) Bosch Power Tools
