Bosch FCP-O320 - Wiring the Detectors

Conventional Automatic Fire Detectors Installation | en 11
Bosch Sicherheitssysteme GmbH
User manual
2021.03 | 11 | F.01U.004.377
Ø 100
X
Ø 120
147.8
22.7
Y
Y
5
5
4.4 Wiring
i
Notice!
Keep screening wire as short as possible and insulate it.
