32 | Operating Temperatures and Pressures EC Series
EC SeriesT111970289 (2015/01) Subject to change without prior notice
OPERATING DATA
COOLING HEATING
MODEL
ENTERING
WATER
TEMP, °F
WATER
FLOW
GPM
SUCTION
PRESSURE
PSIG
DISCHARGE
PRESSURE
PSIG
WATER
TEMP
RISE, °F
AIR TEMP
DROP, °F
SUCTION
PRESSURE
PSIG
DISHARGE
PRESSURE
PSIG
WATER
TEMP
DROP, °F
AIR TEMP
RISE, °F
EC150
EC151
30°
22.0 74-90 244-299 3-4 13-15
38.0 78-95 251-306 2-3 13-16
40°
22.0 122-149 183-224 14-18 19-23 87-106 257-314 4-5 15-18
38.0 117-143 172-210 8-10 20-24 91-111 263-322 3-3 16-19
50°
22.0 131-160 214-261 14-18 18-22 164-201 269-329 5-6 17-20
38.0 126-154 201-245 8-10 19-24 173-211 276-337 3-4 18-22
60°
22.0 136-166 244-298 14-17 18-22 111-136 282-344 6-7 19-23
38.0 131-160 230-281 8-10 19-23 117-143 289-353 4-5 20-24
70°
22.0 141-172 275-336 14-17 17-21 124-152 294-360 7-8 21-25
38.0 135-165 258-316 8-10 18-22 131-160 302-369 5-6 22-27
80°
22.0 145-178 310-378 14-17 17-20 136-166 307-375 8-9 23-28
38.0 140-171 291-356 8-10 18-22 143-175 314-384 5-6 24-30
90°
22.0 150-183 349-426 14-17 16-19 149-182 319-390 8-10 25-30
38.0 144-176 328-401 8-9 17-21 156-191 327-400 6-7 26-32
100°
22.0 155-189 392-480 13-16 16-19
38.0 149-182 369-451 8-9 17-21
EC180
EC181
30°
25.0 64-78 248-303 5-6 15-18
45.0 67-82 254-311 3-4 16-19
40°
25.0 109-134 183-224 18-22 19-23 75-91 261-319 6-8 17-21
45.0 105-128 172-210 10-12 20-25 79-96 267-327 4-5 18-23
50°
25.0 118-144 214-261 18-22 19-23 142-173 273-334 8-10 20-24
45.0 113-138 201-245 10-12 20-24 149-182 280-342 5-7 21-26
60°
25.0 122-149 244-298 17-21 18-22 96-117 286-349 9-11 22-27
45.0 117-143 230-281 10-12 19-24 101-123 293-358 6-8 24-29
70°
25.0 126-154 275-336 17-21 18-22 107-131 299-365 11-13 25-30
45.0 121-148 258-316 10-12 19-23 113-138 306-374 7-9 26-32
80°
25.0 130-159 310-378 17-21 17-21 117-143 311-380 12-15 27-33
45.0 125-153 291-356 10-12 18-22 123-151 319-390 8-10 29-35
90°
25.0 134-164 349-426 17-20 17-20 128-157 324-396 13-16 29-36
45.0 129-158 328-401 9-12 18-22 135-165 332-406 9-11 31-38
100°
25.0 139-170 392-480 16-20 16-20
45.0 133-163 369-451 9-11 17-21
EC210
30°
28.0 71-87 277-339 6-7 15-19
52.0 75-92 284-347 4-5 16-20
40°
28.0 118-144 194-237 21-25 19-23 84-102 291-356 7-9 18-22
52.0 113-138 182-223 12-14 20-24 88-108 299-365 5-6 19-23
50°
28.0 127-155 226-276 21-25 18-22 159-194 305-373 9-11 20-25
52.0 122-149 213-260 12-14 19-24 167-204 313-383 6-7 21-26
60°
28.0 131-160 259-316 21-25 18-22 108-132 320-391 10-13 23-28
52.0 126-154 243-297 12-14 19-23 113-138 328-400 7-9 24-29
70°
28.0 136-166 291-355 20-25 17-21 120-147 334-408 12-15 25-31
52.0 130-159 273-334 12-14 18-22 126-154 342-418 8-10 27-32
80°
28.0 140-171 328-401 20-24 17-20 131-161 348-425 14-17 27-34
52.0 135-165 308-377 11-14 18-22 138-169 356-436 9-11 29-36
90°
28.0 145-177 369-451 20-24 16-20 144-176 362-442 15-18 30-37
52.0 139-170 347-424 11-14 17-21 151-185 371-453 10-12 32-39
100°
28.0 149-183 415-508 19-24 16-19
52.0 143-175 391-477 11-14 17-21
