Operating Temperatures and Pressures | 33EC Series
T111970289 (2015/01)EC Series
OPERATING DATA
COOLING HEATING
MODEL
ENTERING
WATER
TEMP, °F
WATER
FLOW
GPM
SUCTION
PRESSURE
PSIG
DISCHARGE
PRESSURE
PSIG
WATER
TEMP
RISE, °F
AIR TEMP
DROP, °F
SUCTION
PRESSURE
PSIG
DISHARGE
PRESSURE
PSIG
WATER
TEMP
DROP, °F
AIR TEMP
RISE, °F
EC240
EC242
30°
32.0 68-84 256-313 5-7 19-23
64.0 73-89 261-319 4-5 20-25
40°
32.0 113-138 172-210 18-22 19-23 81-99 277-339 7-8 22-26
64.0 110-134 161-196 12-14 20-24 86-105 283-346 5-6 23-28
50°
32.0 116-142 206-252 17-21 19-23 93-114 299-365 8-9 24-29
64.0 112-137 193-236 12-14 19-24 99-121 305-373 6-7 25-31
60°
32.0 118-145 241-294 17-21 18-23 106-129 321-392 9-11 26-32
64.0 115-140 225-275 11-14 19-23 113-138 327-400 7-8 28-34
70°
32.0 121-148 275-336 17-21 18-22 118-145 342-418 10-12 29-35
64.0 117-143 257-314 11-14 19-23 126-154 349-427 8-9 30-37
80°
32.0 123-151 309-378 16-20 18-22 131-160 364-444 11-14 31-38
64.0 120-146 289-353 11-13 19-23 139-170 371-454 8-10 33-40
90°
32.0 126-154 344-420 16-20 18-22 143-175 385-471 12-15 33-41
64.0 122-149 321-392 11-13 18-22 152-186 393-480 9-11 35-43
100°
32.0 128-157 378-462 16-19 17-21
64.0 125-152 353-432 11-13 18-22
EC300
30°
45.0 68-84 256-313 5-7 19-23
75.0 73-89 261-319 4-5 20-25
40°
45.0 117-143 210-256 15-19 21-26 81-99 277-339 7-8 22-26
75.0 114-139 196-239 11-14 22-27 86-105 283-346 5-6 23-28
50°
45.0 120-147 243-297 15-18 20-25 93-114 299-365 8-9 24-29
75.0 117-143 227-277 11-14 21-26 99-121 305-373 6-7 25-31
60°
45.0 123-150 276-337 14-17 20-24 106-129 321-392 9-11 26-32
75.0 119-146 258-315 11-13 21-25 113-138 327-400 7-8 28-34
70°
45.0 126-154 309-378 14-17 19-24 107-131 299-365 11-13 25-30
75.0 121-148 258-316 10-12 19-23 113-138 306-374 7-9 26-32
80°
45.0 130-159 310-378 17-21 17-21 117-143 311-380 12-15 27-33
75.0 125-153 320-391 10-12 19-24 139-170 371-454 8-10 33-40
90°
45.0 132-161 376-459 13-16 18-22 143-175 385-471 12-15 33-41
75.0 128-156 351-429 10-12 19-23 152-186 393-480 9-11 35-43
100°
45.0 134-164 409-500 12-15 17-21
75.0 131-160 382-467 9-11 17-21
EC360
30°
50.0 65-80 282-344 6-7 14-17
90.0 73-89 294-359 3-4 15-18
40°
50.0 121-148 184-225 17-21 18-22 80-98 299-365 7-9 16-20
90.0 117-143 167-204 10-13 19-23 89-108 311-380 4-5 17-21
50°
50.0 123-151 222-271 17-20 17-21 95-116 315-385 9-11 19-23
90.0 119-145 202-247 10-12 18-23 105-128 329-402 5-7 20-24
60°
50.0 125-153 260-318 16-19 17-21 109-133 332-406 11-13 21-26
90.0 120-147 237-289 10-12 18-22 121-148 346-423 6-8 22-27
70°
50.0 127-155 298-365 15-19 17-20 124-151 349-427 12-15 23-28
90.0 122-149 271-331 9-11 18-21 138-168 364-444 7-9 25-30
80°
50.0 129-158 336-411 14-18 16-20 138-169 366-447 14-17 26-31
90.0 124-152 306-374 9-11 17-21 154-188 381-466 8-10 27-33
90°
50.0 131-160 374-458 14-17 16-19 153-187 383-468 16-19 28-34
90.0 126-154 340-416 8-10 17-20 170-208 399-487 9-12 29-36
100°
50.0 133-162 413-504 13-16 15-19
90.0 128-156 375-458 8-10 16-20
