Bosch FHP EC120 - Wiring Diagram with UPM II and FAR

44 | Wiring Diagrams EC Series
EC SeriesT111970289 (2015/01) Subject to change without prior notice
Figure # 29
FOR REFERENCE ONLY Actual unit wiring
may vary from this example. Always refer to the
wiring diagram attached to the unit.
