WATER SIDE PRESSURE DROP
Model Motor
Sheave
Rated
Airflow
External Static Pressure (in wc Wet coil and filter included)
Motor
Sheave
Rated
Airflow
0.2 0.3 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0 2.2
360
Closed – ––––––––– 12900 10800
Half Open 12,00 – ––––13050 11850 10350 7500 –––
Open 12200 11575 10950 9600 7800 –––––––
Model
GPM
Pressure Drop
(PSIG)
Pressure Drop
(ft of H2O)
EC072
10
2.6 6.0
12
3.6 8.3
14
4.8 11.0
16
6.1 14.0
18
7.5 17.3
EC096
12
2.5 5.7
14
3.3 7.5
18
5.1 11.8
21
6.8 15.6
24
8.6 19.8
EC120
16
2.1 4.9
20
3.1 7.3
24
4.4 10.1
28
5.8 13.3
32
7.3 16.9
EC150
20
1.4 3.3
25
2.1 4.9
30
3.0 6.8
35
3.9 9.0
50
7.4 17.1
EC151
20
1.4 3.3
25
2.1 4.9
30
3.0 6.8
35
3.9 9.0
50
7.4 17.1
EC181
22
1.7 3.9
27
2.5 5.7
32
3.3 7.7
42
5.4 12.5
52
8.0 18.4
Model
GPM
Pressure Drop
(PSIG)
Pressure Drop
(ft of H2O)
EC210
30
2.6 5.9
40
4.3 9.9
50
6.4 14.9
60
8.9 20.6
70
11.8 27.2
EC240
30
1.6 3.7
40
2.7 6.2
50
4.0 9.3
60
5.6 12.9
75
8.3 19.2
EC242
30
1.6 3.7
40
2.7 6.2
50
4.0 9.3
60
5.6 12.9
75 8.3 19.2
EC300
40
2.7 6.2
50
4.0 9.3
60
5.6 12.9
75
8.3 19.2
85
10.4 24.1
EC360
50
3.7 8.5
70
6.7 15.5
80
8.5 19.7
90
10.6 24.4
100
12.8 29.5
