OPERATING TEMPERATURES AND
PRESSURES
COOLING HEATING
MODEL
ENTERING
WATER
TEMP, °F
WATER
FLOW
GPM
SUCTION
PRESSURE
PSIG
DISCHARGE
PRESSURE
PSIG
WATER
TEMP
RISE, °F
AIR TEMP
DROP, °F
SUCTION
PRESSURE
PSIG
DISHARGE
PRESSURE
PSIG
WATER
TEMP
DROP, °F
AIR TEMP
RISE, °F
EC072
30°
10.0 65-80 282-344 6-7 14-17
16.0 73-89 294-359 3-4 15-18
40°
10.0 121-148 184-225 17-21 18-22 80-98 299-365 7-9 16-20
16.0 117-143 167-204 10-13 19-23 89-108 311-380 4-5 17-21
50°
10.0 123-151 222-271 17-20 17-21 95-116 315-385 9-11 19-23
16.0 119-145 202-247 10-12 18-23 105-128- 329-402 5-7 20-24
60°
10.0 125-153 260-318 16-19 17-21 109-133 332-406 11-13 21-26
16.0 120-147 237-289 10-12 18-22 121-148 346-423 6-8 22-27
70°
10.0 127-155 298-365 15-19 17-20 124-151 349-427 12-15 23-28
16.0 122-149 271-331 9-11 18-21 138-168 364-444 7-9 25-30
80°
10.0 129-158 336-411 14-18 16-20 138-169 366-447 14-17 26-31
16.0 124-152 306-374 9-11 17-21 154-188 381-466 8-10 27-33
90°
10.0 131-160 374-458 14-17 16-19 153-187 383-468 16-19 28-34
16.0 126-154 340-416 8-10 17-20 170-208 399-487 9-12 29-36
100°
10.0 133-162 413-504 13-16 15-19
16.0 128-156 375-458 8-10 16-20
EC096
30°
13.0 72-87 296-361 5-6 21-25
22.0 75-92 301-368 3-4 22-26
40°
13.0 114-139 155-190 14-17 22-27 88-107 314-384 6-7 24-29
22.0 108-132 147-180 10-12 23-28 92-112 321-392 4-5 25-30
50°
13.0 116-142 192-234 13-16 21-26 104-127 333-407 7-9 27-33
22.0 111-135 182-222 9-12 22-27 109-133 340-415 5-6 28-34
60°
13.0 119-146 228-279 13-16 21-26 120-146 352-430 8-10 30-37
22.0 113-138 217-265 9-11 22-27 125-153 359-439 6-7 32-39
70°
13.0 122-149 264-323 13-15 20-25 136-166 371-453 9-12 33-41
22.0 116-142 251-307 9-11 21-26 142-174 378-462 7-8 35-43
80°
13.0 125-152 301-368 12-15 20-24 152-185 389-476 11-13 36-44
22.0 118-145 286-349 9-11 21-26 159-194 397-485 8-9 38-47
90°
13.0 127-156 337-412 12-15 19-24 168-205 408-499 12-15 39-48
22.0 121-148 320-392 9-10 20-25 176-215 416-509 8-10 41-51
100°
13.0 130-159 374-457 12-14 19-23
22.0 124-151 355-434 8-10 20-24
EC120
30°
16.0 73-89 266-325 5-6 15-18
32.0 77-94 272-333 3-4 16-19
40°
16.0 117-143 189-231 14-71 18-22 86-105 279-341 6-7 17-21
32.0 112-137 178-217 8-9 19-24 90-110 286-350 4-5 18-22
50°
16.0 126-154 221-270 14-17 18-21 162-198 293-358 7-8 20-24
32.0 121-148 207-253 8-9 19-23 170-208 300-366 5-6 21-25
60°
16.0 131-160 252-308 13-16 17-21 110-134 306-374 8-10 22-27
32.0 125-153 237-290 8-9 18-22 115-141 314-383 6-7 23-29
70°
16.0 135-165 284-347 13-16 17-20 122-150 320-391 9-11 24-30
32.0 130-158 266-326 7-9 18-22 129-157 327-400 6-8 26-32
80°
16.0 140-171 320-391 13-16 16-20 134-164 333-407 11-13 27-33
32.0 134-164 300-367 7-9 17-21 141-172 341-417 7-9 28-35
90°
16.0 144-176 360-440 13-16 16-19 147-179 347-424 12-14 29-36
32.0 138-169 338-414 7-9 17-21 154-188 355-434 8-10 31-38
100°
16.0 149-182 405-495 13-15 15-19
32.0 143-174 381-465 7-9 16-20
