Figure: a) Requirements for parts outside radar cone to avoid multipath reflection
The same requirements are valid for a horizontal tilt of the fascia.
3. Technical data with measured variables and measuring conditions
3.1. Mechanical characteristics
Gravel bombardment:
According to ISO 20567-1 against back housing (covered installation)
Mechanical shock:
According to DIN EN 60068-2-27
500m/s^2 / 6ms duration
Mechanical vibration (broadband random vibration):
According to DIN EN 60068-2-64
Frequency spectrum 5 Hz - 2000 Hz according to the following profile
