48
|
Bosch Greenstar Applications Manual
Bosch Thermotechnology Corp.Data subject to change
Bosch
Date
...
Bases
No.
Changed
Released
Created
...
Expansion Tank
Auto-Fill
Air Eliminator
Shut-off
valve
Back-flow
preventer
PRV Relief
Piping
Condensate
drain
Comfort
Room
Controller
Flow Check
Heating
zone
Circulator
Purge Drain
DISCLAIMER: Application drawings
in this manual are conceptual only
and do not purport to address all
design, installation, code, or safety
considerations. The diagrams in
this manual are for reference use by
code officials, designers and
licensed installers. It is expected
that installers have adequate
knowledge of national and local
codes, as well as accepted industry
practices, and are trained on
equipment, procedures, and
applications involved. Drawings are
not to scale. Refer to the boiler,
control and module install
er
manuals for additional detailed
information.
T
T
T
T
T
T
Zone
Valve
Bosch
Bosch
Bosch
CRC100 or
CRC200
CZM100
Comfort
Zone
Manager
Note: See Appendix B for
Primary/Secondary piping
requirements
Gas
Supply
Supply
Sensor
Multi Zone
Heat only wall boiler
Zone Valves
Indirect Tank
NSC Controls
