Bosch GCL100-40G User Manual

-10-
The numbering of the product features shown refers to the illustration of the tool on the graphic page.
1 Laser beam outlet window
2 Battery indicator
3 Button for laser operating mode
4 On/off switch
5 1/4” tripod mount
6 Guide groove
7 Battery compartment cover locking
mechanism
8 Battery compartment cover
9 Laser warning label
10 Serial number
11 Magnetic rotating mount (RM 10)
*
12 Guide rail
13 Fastening slot
14 Fine adjustment knob of the
rotating mount
15 Magnet
16 Ceiling clip (DK 10)
*
17 Universal positioning device (BM 1)
*
18 Magnetic mounting bracket (LB 10)
*
19 Laser receiver
*
20 Laser target plate
*
21 Tripod (BT 150)
*
22 Telescopic shaft (BT 350)
*
23 Laser enhancement glasses
*
24 Hard Carrying Case
*Accessories shown or described are not included with the product as standard. You can find the
complete selection of accessories in our accessories range.
The measuring tool is intended for determining and checking horizontal and vertical lines and plumb
points. The measuring tool is suitable for indoor and outdoor use.
Intended Use
Features

Bosch GCL100-40G Specifications

General

Laser Color	Green
Laser Class	Class 2
Self-Leveling	Yes
Self-Leveling Range	±4°
IP Rating	IP54
Type	Cross-line laser level
Laser Diode	520 nm
Accuracy	±1/8 inch at 30 ft
Working Range	Up to 100 ft
Battery Type	4 x AA
Operating Temperature	-10°C to 50°C
Weight	1.2 lbs
Mount Threading	1/4"
