-12-
The numbering of the product features shown refers to the illustration of the tool on the graphic page.
1 Exit opening for laser
beam
2 Indicator for Bluetooth
®
connection
3 Bluetooth
®
button
4 Charging condition of
battery pack
5 Working without automatic
leveling indicator
6 Receiver mode button
7 Receiver mode indicator
8 Button for laser operating
mode
9 Battery pack*
10 Laser warning label
11 Serial number
12 Tripod mount 1/4”
13 Guide groove
14 On/Off switch
15 Guide rail
16 Magnets
17 Fastening slot
18 Rotating mount (RM 2)*
19 Fine adjustment knob of
rotating platform
20 Ceiling clip (BM 3)*
21 Positioning device BM 1*
22 Laser viewing glasses*
23 Protective pouch*
24 Laser target plate
25 Laser receiver*
26 Hard Carrying Case*
27 Tripod BT 150*
28 Telescopic rod BP350*
*The accessories illustrated or described are not included as standard delivery.
Features
Technical Data
Laser Model GCL100-80C GCL100-80CG
Working range (typical)
1)
–without laser receiver
–with laser receiver
–Upward laser point
–Downward laser point
up to 100 ft (30 m)
15-165 ft (5-50 m)
30 ft (10 m)
30 ft (10 m)
up to 100 ft (30 m)
15-165 ft (5-50 m)
30 ft (10 m)
30 ft (10 m)
Leveling Accuracy
–Laser lines
–Laser points
±1/8 in. at 30 ft (3 mm at 10 m)
±9/32 in. at 30 ft (7 mm at 10 m)
±1/8 in. at 30 ft (3 mm at 10 m)
±9/32 in. at 30 ft (7 mm at 10 m)
Self-leveling range (typical) ±4° ±4°
Leveling duration (typical) <4s <4s
Operating temperature 14 °F ~122 °F
(–10 °C ~ +50 °C)
14 °F ~122 °F
(–10 °C ~ +50 °C)
Storage temperature
–Laser Level
–Battery
-4 °F ~ 158 °F (–20 °C ~ +70 °C)
32 °F ~122 °F (0 °C ~ +50 °C)
-4 °F ~ 158 °F (–20 °C ~ +70 °C)
32 °F ~122 °F (0 °C ~ +50 °C)
Charging temperature 32 °F ~ 113 °F
(0 °C ~ +45 °C)
32 °F ~ 113 °F
(0 °C ~ +45 °C)
Max. altitude 6560 ft (2000 m) 6560 ft (2000 m)
Relative air humidity, max. 90 % 90 %
Pollution degree according IEC
61010
4)
2 2
Laser class 2 2
2610050715 5-19 GCL100-80CCG.indd 12 6/6/19 7:06 AM
