English | 9
Bosch Power Tools 2 609 141 167 | (15.4.14)
Product Features
The numbering of the product features shown refers to the illustration of the measur-
ing tool on the graphic page.
1 Display
2 Measuring button
3“–” button
4 Function button
5 On/Off button
6“+” button
7 Battery lid
8 Latch of battery lid
9 Serial number
10 Laser warning label
11 Reception lens
12 Laser beam outlet
13 Laser target plate*
14 Laser viewing glasses*
15 Protective pouch*
* The accessories illustrated or described are not included as standard delivery.
Display Elements
a Temperature warning
b Battery low indicator
c Measuring functions
d Measurement reference level
e Unit of measure
f Current measuring value
g Memory value display
h Previous measuring value
i Error message “Error”
Length measurement
Continuous measurement
Area/surface measurement
Volume measurement
Simple Pythagoras Measurement
