English | 11
1 609 929 M05 • 9.7.07
Measured values determined according to
EN 60 745.
Typically the A-weighted noise levels of the ma-
chine are: sound pressure level 96 dB (A); sound
power level 107 dB (A). Uncertainty K = 3 dB.
Wear hearing protection!
Vibration total values (triax vector sum) deter-
mined according to EN 60 745:
Drilling into metal: Vibration emission value a
h
=
2.5 m/s
2
, Uncertainty K=1.5 m/s
2
,
Impact drilling into concrete: Vibration emission
value a
h
=14 m/s
2
, Uncertainty K=3.5 m/s
2
.
The vibration emission level
given in this information sheet
has been measured in accordance with a stand-
ardised test given in EN 60745 and may be used
to compare one tool with another.
The vibration emission level will vary because of
the ways in which a power tool can be used and
may increase above the level given in this infor-
mation sheet. This could lead to a significant un-
derestimate of exposure when the tool is used
regularly in such a way.
NOTE: To be accurate, an estimation of the level
of exposure to vibration experienced during a
given period of work should also take into ac-
count the times when the tool is switched off and
when it is running but not actually doing the job.
This may significantly reduce the exposure level
over the total working period.
We declare under our sole responsibility that the
product described under „Technical data“ is in
conformity with the following standards or
standardization documents: EN 60745 according
to the provisions of the directives 2004/108/EC,
98/37/EC (until 28 Dec 2009), 2006/42/EC (from
29 Dec 2009).
Dr. Egbert Schneider Dr. Eckerhard Strötgen
Senior Vice President Head of Product
Engineering Certification
18.06.2007, Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
The numbering of the product features refers to
the illustration of the machine on the graphics
page.
While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.
1 Key type drill chuck
2 “Drilling/Impact Drilling” selector switch
3 Lock-on button
4 On/Off switch
5 Chuck key
6 Depth stop
7 Gear selector
8 Wing bolt for depth stop adjustment
9 Auxiliary handle
Illustrated or described accessories are not included as
standard delivery.
Tool Specifications
Impact Drill GSB 90-2 E
Professional
Article number 0 601 183 7..
Rated power input [W] 1 150
Output power [W] 670
Rated speed
1st gear [rpm] 0 – 700
2nd gear [rpm] 0 – 2 100
Impact rate, max.
1st gear [bpm] 14 000
2nd gear [bpm] 42 000
Rated torque
(1st/2nd gear)
[Nm] 40/16
Chuck clamping range [mm] 3–16
Maximum drilling Ø
(1st/2nd gear)
Stone [mm] 35/16
Concrete [mm] 68/90
Steel [mm] 16/10
Wood [mm] 50/30
Weight according to
EPTA-Procedure 01/
2003
[kg] 4.0
Protection class / II
The values given are valid for nominal voltages [U] of 230/
240 V. For lower voltages and models for specific coun-
tries, these values can vary.
Please observe the article number on the type plate of your
machine. The trade names of the individual machines may
vary.
Noise/Vibration Information
WARNING
Declaration of Conformity
Product Features
1 609 929 M05.book Seite 11 Montag, 9. Juli 2007 2:31 14
