English | 15
Bosch Power Tools 1 609 929 R01 | (2.4.08)
Functional Description
Read all safety warnings and all in-
structions. Failure to follow the
warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.
While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.
Intended Use
The power tool is designed for chiselling in con-
crete, brick, stones and asphalt as well as,
equipped with the corresponding accessories,
for taking off tiles, plaster, rests of glue and
stucco.
Product Features
The numbering of the product features refers to
the illustration of the machine on the graphics
page.
1 Dust protection cap
2 Locking sleeve
3 Chisel adjustment ring (Vario-Lock)
4 Lock-on button for On/Off switch
5 On/Off switch
6 Auxiliary handle
The accessories illustrated or described are not in-
cluded as standard delivery.
Technical Data
Declaration of Conformity
We declare under our sole responsibility that
the product described under “Technical Data” is
in conformity with the following standards or
standardization documents: EN 60745 accord-
ing to the provisions of the directives
2004/108/EC, 98/37/EC (until 28 Dec 2009),
2006/42/EC (from 29 Dec 2009), 2000/14/EC.
2000/14/EC: Measured sound power level
101 dB(A). Conformity assessment procedure
according to Annex VI.
Notified body:
TÜV NORD CERT GmbH & Co. KG,
Am TÜV 1, 30519 Hannover
Technical file at:
Robert Bosch GmbH, Postfach 10 01 56,
D-70745 Leinfelden-Echterdingen
Leinfelden, 12.03.2008
Demolition Hammer GSH 3 E
Professional
Article number
0 611 320 7..
Rated power input
W 650
Impact rate
bpm 0– 3500
Impact energy per
stroke
J4.3
Chisel positions
12
Chiselling capacity in
concrete of medium
hardness
kg/h 31
Tool holder
SDS-plus
Lubrication
Oil lubrication
Weight according to
EPTA-Procedure
01/2003
kg 3.5
Protection class
/II
The values given are valid for nominal voltages [U] of
230/240 V. For lower voltage and models for specific
countries, these values can vary.
Please observe the article number on the type plate of
your machine. The trade names of the individual ma-
chines may vary.
