English - 1
Measured values determined according to
2000/14/EC (1.60 m height, 1 m distance away)
and EN 50 144.
Typically the A-weighted noise levels of the prod-
uct are: sound pressure level: 88 dB (A); sound
power level: 101 dB (A).
Wear hearing protection!
The typical weighted acceleration is 11 m/s
2
.
The machine is intended for chiselling work in
concrete, brick, stone and asphalt as well as for
driving and compacting with appropriate acces-
sories.
1 Dust protection cap
2 Locking sleeve
3 Chisel adjusting ring (Vario-lock)
4 Vibration damper
5 On/Off switch
6 Impact rate control
7 Service indicator
8 Stand-by-indicator
9 Auxiliary handle
Not all of the accessories illustrated or described are
included as standard delivery.
Working safely with this ma-
chine is possible only when the
operating and safety information
are read completely and the in-
structions contained therein are
strictly followed. In addition, the
general safety notes in the en-
closed booklet must be ob-
served. Before using for the first
time, ask for a practical demon-
stration.
■ Wear hearing protection.
■ Wear safety glasses and sturdy shoes.
■ If the mains cable is damaged or cut through
while working, do not touch the cable but im-
mediately pull the mains plug. Never use the
machine with a damaged cable.
■ Connect machines that are used in the open via
a residual current device (RCD) with an actuat-
ing current of 30 mA maximum. Use only exten-
sion cables that are approved for outdoor use.
■ Use appropriate detectors to determine if
utility lines are hidden in the work area or
call the local utility company for assist-
ance.
Contact with electric lines can lead to fire and
electric shock. Damaging a gas line can lead
to explosion. Penetrating a water line causes
property damage or may cause an electric
shock.
■ Hold the power tool only by the insulated
gripping surfaces, when performing an op-
eration where the cutting tool may run into
hidden wiring or its own cord.
Contact with a “live” wire will make exposed
metal parts of the tool “live” and shock the op-
erator.
■ Always direct the cable to the rear away from
the machine.
■ Insert the mains plug only when the machine is
switched off.
■ Use the machine only with the auxiliary han-
dle 9.
■ When working with the machine, always hold it
firmly with both hands and provide for a secure
stance.
■ Always switch the machine off and wait until it
has come to a standstill before placing it down.
■ Never allow children to use the machine.
■ Bosch is only able to ensure perfect operation
of the machine if the original accessories in-
tended for it are used.
Tool Specifications
Demolition Hammer GSH 5 E
Order number 0 611 318 7..
Rated power [W] 1 100
Impact rate [bpm] 2 900
Impact energy per
stroke
[J] 2–12
Chisel positions 12
Chiselling performance
in concrete of medium
hardness
[kg/h] 180
Tool holder SDS-max
Lubrication Oil lubrication
Weight (without
accessories) approx.
[kg] 5.4
Protection class / II
Please observe the order number of your machine. The
trade names of the individual machines may vary.
Noise/Vibration Information
Intended Use
Machine Elements
For Your Safety
10 • 1 619 929 577 • TMS • 22.02.02
