9
Dimensions and clearances required
Installation for best performance
9 CAUTION
DO NOT INSTALL THE DRYER:
▯ outdoors,
▯ in an environment with dripping water,
▯ near flammable materials,
▯ in rooms which are at risk of freezing,
▯ in rooms which may contain gas or other fuels,
▯ on carpets.
The dryer should be installed in an open area with no
restrictions to ambient air for the best drying results.
Space allowances to fully open the door should also be
considered.
Do not operate the dryer at temperatures above 95°F
(35°C) or below 41°F (5°C). Low temperatures affect
the drying process and may prolong the drying times.
The installation surface (floor) must be level and
structurally sound. Using the bubble level and the height-
adjustable feet installed on the appliance, level the
appliance side to side and front to back.
Appliance dimensions
Length of power cord and drain hose
Minimum clearances
Closet: Stacked
Label Dimension U.S.
Inches
Metric
cm
a Width 23.6 60
b Depth (to front of door) 25 63.5
c Height (minimum)
Height (maximum)
33.2
34
84.3
86.4
D
E
F
G
H
d Side clearance
(door open 180°)
16 40.6
e
Depth (door open 90°)
42.9 109
To Left* To Right*
U.S.
Inches
Metric
cm
U.S.
Inches
Metric
cm
Power Cord 42 106.7 60 152.4
Drain Hose 76 193 55 139.7
* Facing the front of the dryer
Label Dimension U.S.
Inches
Metric
cm
$
%
&
'
(
)
+
*
