-9-
NOTE: For tool specifications refer to the nameplate on your tool.
Model number JS470E & JS470EB
Maximum
Capacities
Stroke length 1" (25 mm)
Wood 3-1/2" (89 mm)
Aluminium 13/16" (20.6 mm)
Mild steel 5/16" (8 mm)
Functional Description and Specifications
VARIABLE
SPEED DIAL
(Model
JS470EB)
SLIDE ON-OFF
SWITCH
(Model JS470EB
only)
Jig Saw JS470EB
INSULATED GRIPPING
SURFACES
INSULATED
GRIPPING
SURFACES
Fig. 1b
