2 Controlling Allegiant Series Video Switchers
Before you can take control of an Allegiant Video Switcher, you may have to perform a log-on
procedure to gain access to the Allegiant Main Control menu to control the switcher.
Note: This chapter applies to the KBD-Universal Model only.
– The keyboard generates a short, audible “beep” when first entering the Allegiant log-in
screen. This beep notifies operators that the keyboard is ready to accept user number
and password data. The keyboard may not correctly accept data entered before this
beep.
– If log-on information is required, the status display requests a USER NUMBER. Enter the
number using the keypad and press ENTER.
– The status display requests a PASSWORD. Enter the password using the keypad and
press ENTER.
– If an invalid user number or password is entered, the status display requests the log-on
again.
– Following a successful log-on, the softkey display shows the Allegiant Main Control menu,
as illustrated in
– If user log-on is not required, the softkey display shows USER LOGGED ON briefly, then
displays the Allegiant Main Control menu. The menu displayed depends on the camera
display mode, either four-digit or six-digit.
Figure 2.1 Status Display in Four-digit Allegiant Mode
Figure 2.2 Status Display in Six-digit Allegiant Mode
Monitor
123
Camera
1234
Allegiant
Monitor
123
Camera
1234
Allegiant
99
