Bosch KBR28-3A - Product dimensions and minimum clearances

Information about the appliance
Greenstar FS/Combi FS – 6 720 810 590 (2020/04)
8
3.6 Product dimensions and minimum clearances
Fig. 4
[M1] 18
3
/
8
” - (467mm)
[M2] 3
1
/
2
” - (88mm)
[M3] 9
5
/
8
” - (243.5mm)
[M4] 10” - (253.5mm)
[M5] 39
1
/
2
” - (1003mm)
[M6] 11
7
/
8
” - (301.5mm)
[M7] 7
7
/
8
” - (200mm)
[M8] 4” - (101mm)
[M9] 8
3
/
16
” - (207.3mm)
[M10] 3
7
/
16
” - (86.7mm)
[M11] 6
13
/
16
” - (173.3mm)
[M12] 4
5
/
8
” - (117.6mm)
[M13] 11
3
/
16
” - (283mm)
[M14] 5
1
/
8
” - (131mm)
[M15] 28
1
/
16
” - (713.5mm)
[M16] 31” - (788mm)
[Ø 1] 3
1
/
8
” - (80mm)
[Ø 2] 4
15
/
16
” - (125mm)
Table 3
M2
M1
M3 M4
M6
M8
M7
M9
M10
M11
M12
M14
M13
Ø1
Ø2
M15
M16
M5
6720810590-36.1Wo
Symbol Description Connection size
Domestic water inlet
3
/
4
” - (19mm)
Domestic hot water outlet
3
/
4
” - (19mm)
Heating return 1
1
/
4
” - (31.8mm)
Heating supply 1
1
/
4
” - (31.8mm)
Gas supply
3
/
4
” - (19mm)
