To open the quick-connect, push in on the tabs. Connections are not
polarity sensitive Use stranded or solid wire AWG16 to AWG22, cut
back 10mm (0.4") of insulation.
Composite Video
Y/C output (LTC 0455/x1 only)
LENS MOUNTING
Pin Y/C Socket
1GND Y
2GND C
3Y
4C
