Figure 5.1: Midspan_DataIn_DataOut_Connections
1
AC input connectivity indicator
2 Port connectivity indicator
3 CAT5 cable
4 Connection to camera
5 Connection to Ethernet switch
High PoE Midspans Connection | en 17
Bosch Security Systems 2015.06 | 3.1 | F.01U.304.912
