Connection
Notice!
The PoE ports “Data In“ and “Data & Power Out“ are shielded
RJ45 data sockets. They cannot be used as “Plain Old
Telephone Service” (POTS) telephone sockets. Connect only
RJ45 data connectors (EIA 568A and 568B) to these ports.
The “Data In” and “Data & Power Out” interfaces are qualified
as “Safety Extra Low Voltage” (SELV) circuits according to IEC
60950-1. These interfaces can be connected only to SELV
interfaces on other equipment.
1. Connect the midspan to an AC power outlet (100 – 240
VAC), using one of the two power cords supplied, or one
that has the appropriate ratings and specifications (see the
Safety chapter).
Note: The voltage of the power outlet must match the
voltage indicated on the midspan label.
2. Connect the Data In (input) port to the remote Ethernet
network switch.
3. Connect the Data & Power Out (output) port to the
Ethernet port on the AutoDome camera.
Note: Do NOT use cross-over cable!
5
16 en | Connection High PoE Midspans
2015.06 | 3.1 | F.01U.304.912 Bosch Security Systems
