Troubleshooting
The following tables identify the LED indicators on the top of
the midspan.
AC (Main) LED Indicator (60 W and 95 W)
AC (Main)
LED
OFF Green
Green Power off indicator Power on indicator
(power is active)
Port LED Indicator (60 W)
Port LED
Behavior
– OFF – No detection or disconnected or no
load is connected.
– Yellow ON – Power is supplied over the data pair
or over the spare pair.
– Green ON – Power is supplied over the data and
spare pairs together.
– Blinking yellow
at 1 Hz rate
– Over current or short circuit
condition at one of the 2 pairs (the
other pair is OFF) - data or spare,
(PD or cable fault)
– Blinking yellow
and green
at 1 Hz rate
– Over current or short circuit
condition at one or both pairs - data
or/and spare, (PD or cable fault)
– Blinking yellow
or green at 4
Hz rate
– Internal fault condition
6
