Product Features
The numbering of the product features shown refers to the il-
lustration of the measuring tool on the graphic page.
1 Laser line
2 Exit opening for laser beam
3 Plumb beam
4 Automatic levelling indicator
5 Operating-mode indication
6 Operating mode button
7 On/Off switch
8 Tripod mount 1/4"
9 Latch of battery lid
10 Battery lid
11 Laser warning label
12 Tripod*
13 Wall holder*
14 Unlocking buttons of the holding plate
15 Holding plate of the wall mount
16 Fastening screw for wall mount
17 1/4" screw of wall mount
18 Laser viewing glasses*
19 Protective pouch
* The accessories illustrated or described are not included as
standard delivery.
Technical Data
Assembly
Inserting/Replacing the Battery
Using alkali-manganese or rechargeable batteries is recom-
mended for operation of the measuring tool.
To open the battery lid 10, press on the latch 9 and fold the
battery lid up. Insert the batteries/rechargeable batteries.
When inserting, pay attention to the correct polarity accord-
ing to the representation on the inside of the battery lid.
Always replace all batteries/rechargeable batteries at the
same time. Do not use different brands or types of batter-
ies/rechargeable batteries together.
f Remove the batteries/rechargeable batteries from the
measuring tool when not using it for longer periods.
When storing for longer periods, the batteries/rechargea-
ble batteries can corrode and discharge themselves.
Operation
Initial Operation
f Protect the measuring tool against moisture and direct
sun light.
f Do not subject the measuring tool to extreme tempera-
tures or variations in temperature. As an example, do
not leave it in vehicles for longer periods. In case of large
variations in temperature, allow the measuring tool to ad-
just to the ambient temperature before putting it into oper-
ation.
f Avoid heavy impact to or falling down of the measuring
tool. Damage to the measuring tool can impair its accura-
cy. After heavy impact or shock, compare the laser lines or
plumb beams with a known horizontal or vertical reference
line or with already checked plumb points.
f Switch the measuring tool off during transport. When
switching off, the levelling unit, which can be damaged in
case of intense movement, is locked.
Switching On and Off
To switch on the measuring tool, push the On/Off switch 7 to
the “On” position. Immediately after switching on, the meas-
uring tool sends out the two laser lines 1.
f Do not point the laser beam at persons or animals and
do not look into the laser beam yourself, not even from
a large distance.
To switch off the measuring tool, slide the On/Off switch 7 to
the “Off” position. When switching off, the levelling unit is
locked.
f Do not leave the switched on measuring tool unattend-
ed and switch the measuring tool off after use. Other
persons could be blinded by the laser beam.
Operating Modes (see figures A –E)
After switching on, the measuring tool is in cross-line operat-
ing mode with automatic levelling.
To change the operating mode, press the “Mode” button 6
until the requested operating mode is indicated by the corre-
sponding illuminated operating-mode indication 5.
Cross-line Laser PCL 20
Article number
3 603 K08 2..
Working range to approx.
10 m
Levelling accuracy
–Laser line
– Plumb beam (upward)
– Plumb beam (downward)
± 0.5 mm/m
± 0.5 mm/m
± 1 mm/m
Self-levelling range, typically
± 4°
Levelling duration, typically
4s
Operating temperature
+5 °C...+40 °C
Storage temperature
–20 °C...+70 °C
Relative air humidity, max.
90 %
Laser class
2
Laser type
–Laser line
– Plumb beam
635 nm, <2 mW
650 nm, <2 mW
C
6
(laser line) 10
Tripod mount
1/4"
Batteries
Rechargeable batteries
4 x 1.5 V LR06 (AA)
4x1.2VHR06(AA)
Operating life time, approx. 40 h
Weight according to EPTA-Procedure
01/2003
0.5 kg
Dimensions (length x width x height)
123 x 67 x 110 mm
Please observe the article number on the type plate of your measuring
tool. The trade names of the individual measuring tools may vary.
OBJ_BUCH-725-004.book Page 10 Tuesday, July 26, 2011 8:04 AM

Bosch PCL 20 Specifications

General

Type	Line level
Product color	Black, Green
Tripod thread	1/4 \
Tripod mounting supported	Yes
Laser class	2
Laser diode	635 nm (\u003C 1 mW)
Maximum range	10 m
Color of laser beam	Red
Leveling accuracy (±)	0.5 mm/m
Self-leveling range (±)	4 °
Battery type	AA
Operating time	35 h
Battery voltage	1.5 V
Battery technology	Alkaline
Number of batteries supported	4
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	5 - 40 °C

Weight and Dimensions

Depth	123 mm
Width	67 mm
Height	110 mm
Weight	480 g
