6
2. Replace the nozzles using the appropriate wrench
and tighten them carefully to guarantee the seal.
→Fig.
15
, →Fig.
16
Ensure that the nozzle does not become detached
during removal or fastening.
Removing the cover
1. Remove the pan supports, burner caps, distribut-
ors and rotary knobs.
2. Undo the screws on the burners.
3. Carefully remove the cover.
Reinstalling the appliance
▶ Install the appliance components in reverse order.
Checking if equipment is working
1. Check that turning the rotary knob between the
position for maximum power and the position for
minimum power does not cause the burner to go
out or result in backfire.
2. If the gas flow from the burner is not correct:
‒ In the table →Fig.
17
, check whether the nozzle
and the bypass screw are correct.
‒ Tighten or loosen the bypass screw until the
gas flow from the burner is correct.
Documenting the gas type conversion
▶ Attach the sticker showing the new gas type near
to the rating plate.
