Symbols
The following symbols are important for reading and understanding the operating instructions.
Please take note of the symbols and their meaning. The correct interpretation of the symbols will
help you to use the machine in a better and safer manner.
Delivery Scope
Cordless Drill/Driver.
Battery, application tools and other accessories
shown or described are not part of the standard
delivery scope.
A complete overview of accessories can be
found in our accessories program.
Intended Use
The machine is intended for driving in and loos-
ening screws as well as for drilling in wood, met-
al, ceramic and plastic.
Symbol Meaning Symbol Meaning
PSR 10,8 LI-2: Cordless
Drill/Driver
Grey-marked area: Handle (in-
sulated gripping surface)
Article number
Read all safety warnings and all
instructions
Before any work on the machine
itself, remove the battery
Movement direction Reaction direction
Right/left rotation Drilling
Low speed High speed
Switching On Switching Off
U Rated voltage n
0
1 No-load speed (1. gear)
n
0
2 No-load speed (2. gear) M Maximum torque according to
ISO 5393
Metal Wood
Ø Drilling diameter, max. Ø Max. screw dia.
Chuck clamping range Weight according to
EPTA-Procedure 01/2003
L
wA
Sound power level L
pA
Sound pressure level
K Uncertainty a
h
Vibrational emission value
