Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted sound pressure level of the product
is 75 dB(A). Uncertainty K=3 dB.
The noise level when working can exceed 80 dB(A).
Wear hearing protection!
Vibration total values (triax vector sum) determined accord-
ing to EN 60745:
Drilling into metal: Vibration emission value a
h
<2.5m/s
2
, Un-
certainty K=1.5 m/s
2
,
Screwdriving: Vibration emission value a
h
<2.5m/s
2
, Uncer-
tainty K=1.5 m/s
2
.
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.
Technical Data
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2004/108/EC,
2006/42/EC.
Technical file at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
10.03.2011
Assembly
Battery Charging
A battery that is new or has not been used for a longer period
does not develop its full capacity until after approx. 5 charg-
ing/discharging cycles.
To remove the battery 9 press the unlocking buttons 8 and
pull out the battery downwards. Do not exert any force.
The battery is equipped with a NTC temperature control
which allows charging only within a temperature range of be-
tween 0 °C and 45 °C. A long battery service life is achieved
in this manner.
A significantly reduced working period after charging indi-
cates that the battery is used and must be replaced.
Observe the notes for disposal.
Changing the Tool (see figure A)
f Before any work on the machine (e. g., maintenance,
tool change, etc.) as well as during transport and stor-
age, set the rotational direction switch to the centre
position. Unintentional actuation of the On/Off switch can
lead to injuries.
Cordless Drill/Driver PSR 12 PSR 14,4 PSR 18
Article number
3 603 J55 5.. 3 603 J55 4.. 3 603 J55 3..
Rated voltage
V= 12 14.4 18
No-load speed
min
-1
0–700 0–700 0–700
Max. torque for hard/soft screwdriving application ac-
cording to ISO 5393 Nm 26/11 28/12 30/13
Max. screw dia.
mm 8 88
Max. drilling dia.
– Steel
– Wood
mm
mm
10
20
10
25
10
28
Chuck clamping range
mm 0.8–10 0.8–10 0.8–10
Weight according to EPTA-Procedure 01/2003
kg 1.4 1.5 1.7
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
