Bosch PVQ731F15E User Manual

en Operating modes
8
Sensor Function
⁠ PowerBoost
Intensive ventilation settings
⁠ Timer function
⁠ Manual ventilation control
Depending on the status of the hob, the displays for
the cooking zones and the various activated and avail-
able functions also light up.
5.5 Distribution of the cooking zones
The specified power has been measured with the
standard pots, which are described in IEC/EN
60335-2-6. The power may vary depending on the size
of the cookware or cookware material.
A A
AA
Area Highest power level
⁠ 21 cm diameter ⁠
⁠
Power level 9
PowerBoost
2200W
3700W
⁠ 21 x 38 cm ⁠ Power level 9 3600W
5.6 Cooking zone
Before you start cooking, check whether the size of the
cookware fits the cooking zone that you want to use for
cooking:
Area Cooking zone type
⁠ ⁠ Single-circuit cooking zone
⁠
Combi cooking zone →Page11
5.7 Residual heat indicator
The hob has a residual heat indicator for each cooking
zone. Do not touch the cooking zone if the residual
heat indicator is lit.
Display Meaning
⁠ The cooking zone is hot.
⁠ The cooking zone is warm.
6 Operating modes
You can use your appliance in air extraction mode or
circulating-air mode.
6.1 Air extraction mode
The air which is drawn in is cleaned by the grease fil-
ters and conveyed to the exterior by a pipe system.
The air must not be discharged into a
flue that is used for exhausting fumes
from appliances burning gas or other
fuels (not applicable to appliances that
only discharge the air back into the
room).
¡ If the exhaust air is to be conveyed
into a non-functioning smoke or ex-
haust gas flue, you must obtain the
consent of the heating engineer re-
sponsible.
¡ If the exhaust air is conveyed
through the external wall, a tele-
scopic duct should be used.
6.2 Air recirculation mode
The air which is drawn in is cleaned by the grease fil-
ters and an odour filter, and conveyed back into the
room.
To bind odours in circulating-air mode,
you must install an odour filter. The dif-
ferent options for operating the appli-
ance in circulating-air mode can be
found in our catalogue. Alternatively,
ask your dealer. The required accessor-
ies are available from specialist retail-
ers, from customer service or from the
Online Shop.

Bosch PVQ731F15E Specifications

General

Built-in hood	Yes
Type of extraction	Recirculating
Fan noise level (max)	74 dB
Fan noise level (min)	69 dB
Maximum extraction power	622 m³/h
Hob type	Zone induction hob
Product color	Black
Hob width size	70 cm
Top surface type	Ceramic
Appliance placement	Built-in
Cooking zone 1 boost	3700 W
Cooking zone 1 power	2200 W
Cooking zone 1 position	Left front
Cooking zone 2 position	Left rear
Cooking zone 3 position	Right rear
Cooking zone 4 position	Right front
Number of cooking zones	4 zone(s)
Cooking zone 1 power source	Gas
Cooking zone 2 power source	Electric
Cooking zone 2 size (W x D)	190 x 210 mm
Number of gas cooking zones	0 zone(s)
Timer type	Digital
Control type	Touch
Built-in display	-
Control position	Front / Top front
AC input voltage	220-240 V
AC input frequency	50-60 Hz
Connected load (gas)	- W
Connected load (electric)	7400 W
Package depth	660 mm
Package width	940 mm
Package height	430 mm
Package weight	30000 g
Keep warm function	No
Number of boosters	9
Number of power levels	17

Weight and Dimensions

Depth	522 mm
Width	710 mm
Height	223 mm
Weight	25200 g
Cord length	1.1 m
Installation compartment width	560 mm
Installation compartment depth (min)	490 mm
