To complete the installation, the
burner covers must be fitted
onto their corresponding rings.
In addition, the pan supports
must also be located in their
correct places.
Removal of hob
Turn off the appliance’s
electricity and gas supply.
Unscrew the clips and proceed
in the reverse order to
installation.
Warning! If any connection is
handled, check the seal.
Danger of leaks.
The manufacturer is not liable for
any connection leaking, after being
handled.
Electrical connection
Check that the voltage and power of
the appliance are compatible with
the electrical installation.
The hobs are supplied with a power
cable with a wall socket plug.
Provide an omnipolar cut-off switch
with a minimum contact separation
of 3 mm (except for plug connections,
if the user has access to it).
Appliances with plugs must only
be connected to sockets that have
earth wires correctly installed.
This appliance is type “Y”: the
supply cable can only be
changed
by the Technical Assistance
Service and not by the user. The
cable type and minimum cross-
section
(3 x 0.75 mm²) must be respected.
Robert Bosch Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München
1032xxx – 02.2018
