1 System presentation
1.1 Brief Description of the VDP 16.3, VDP 40.3 and VDP 60.3
Operator Displays
The VDP 16.3/40.3/60.3 operator displays are passive operator and
visualization terminals. They form a PC-based operator terminal when used
with a control cabinet PC equipped with a CDI or CDI+ interface. Currently,
the VSB 40.3 and the VPB 40.3 devices are available as control cabinet PCs.
While the VDP 16.3, VDP 40.3 and VDP 60.3 displays are mounted in the
door of the control cabinet or on a bracket with little mounting depth, the
control cabinet PC can for example be mounted in the control cabinet. The
data transmission between control cabinet PC and a VDP 16.3, VDP 40.3 or
VDP 60.3 operator display is carried out via the CDI interface.
1.1.1 Y-repeater
A Y-repeater is an accessory to connect VDP devices to a control cabinet PC
with CDI interface (see chapter 1.3 "Accessories" on page 5). The Y-
repeater can be used to connect two VDP devices to a control cabinet PC
with CDI interface. For more information on the Y-repeater, refer to the
operating instructions R911336973.
The Y-repeater can only be connected to a control cabinet PC
with CDI interface. An operation at the control cabinet PC with
CDI+ interfaces is not possible.
1.2 Variants
Die operator displays of the VDP xx.3 devices are available with CDI
interface and CDI+ interface.
CDi VDPxx.3xxx-D1-xx-xx
CDI+ VDPxx.3xxx-D2-xx-xx
Tab. 1-1: Type code for CDI interfaces and CDI+ interfaces
1.2.1 Characteristic features
The displays are available as different variants, see type designation code in
chapter 11 "Ordering information" on page 47. They differ in display size
and touch screen capability.
VDP 16.3 DB – BK
Customized design for Bosch – AK –
Display 304.8 mm TFT (12")
Touch screen Yes Yes No
Keys (foil keyboard) No No 16 machine
function keys
Tab. 1-2: Characteristic features of the VDP 16.3 devices
IndraControl VDP 16.3, VDP 40.3, VDP 60.3 Operator Display
1/57
System presentation
R911323862_Edition 07 Bosch Rexroth AG
