Bosch Rexroth Marex SB - Page 7

4
General
OverviewWiringAdjustmentOperationError AnalysisAppendix
Single engine - mechanical throttle control, electrical gear shifting
Throttle is actuated by mechanical rods, gear shifting is controlled by 24 V-signals.
1
2
3
4
5
6
7
8
1
A2
70 mm
100 N
24 V
shielded cable
type LIYCY
4 x 1 mm
2
shielded cable
type LIYCY
7 x 1 mm
2
SYSCON
Single engine – electrical throttle control and gear shifting
Throttle is adjusted electrically (4 ... 20 mA), the gears are shifted using 24 V-signals.
1
2
3
4
5
6
7
8
1
24 V
4...20 mA
shielded cable
type LIYCY
4 x 1 mm
2
shielded cable
type LIYCY
7 x 1 mm
2
shielded cable
type LIYCY
2 x 0,75 mm
2
SYSCON
