This machine is intended for domestic lawn mowing.
Intended Use is related to operation within 0 °C and
40 °C ambient temperature.
This manual gives instructions on the correct as-
sembly and safe use of your machine. It is important
that you read these instructions carefully.
When fully assembled the machine weighs approxi-
mately 7 kg. If necessary, obtain assistance to re-
move from packaging.
Take care when carrying the mower to the lawn, as
the blades are sharp.
Carefully remove the machine from its packaging
and check that you have all the following items:
– Lawnmower with handle assembly
– 2 Handle bottoms
– 2 Bolts
– 2 Wing nuts
– 2 Screws
– 2 Grassbox halves
– 2 Cable clips
– Operating instructions
When parts are missing or damaged, please contact your
dealer.
1
Switch lever
2
Safety button
3
Handle top
4
Mains plug**
5
Cable restraint**
6
Grassbox
7
Deflector guard
8
Handle bottom
9
Serial Number
10
Wheels
11
Ventilation slots
12
Height of cut indicator
**Country specific
Not all of the accessories illustrated or described are
included as standard delivery.
Electrical Safety
Your machine is double insulated for safety and re-
quires no earth connection. The operating voltage is
230 V AC, 50 Hz (for non-EU countries 220 V, 240 V
as applicable). Only use approved extension cables.
Contact your service agent for details.
Extension cords/leads should only be used if they
comply with H05VV-F or H05RN-F types.
It is recommended for increased electrical safety to
use a Residual Current Device (RCD) with a tripping
current of not more than 30 mA. Always check your
RCD every time you use it.
For products not sold in GB:
WARNING: For safety, it is essential that the
mains plug
4
attached to the machine is fitted to the
power supply cable
14
.
The couplings of connection leads must be pro-
tected against splashes and the coupling sockets on
the leads must be made of rubber or coated with rub-
ber.
Fixing means for the connection leads must be used.
The power cord must be inspected for signs of dam-
age at regular intervals and may only be used if in
perfect condition.
Product Specification
Lawnmower
ROTAK 320
Part number
3 600 H85 ..
Rated power [W] 1000
Blade width [cm] 32
Height of cut [mm] 20–60
Grassbox capacity [l] 28
Weight [kg] 7.0
Protection class
/ II
Serial Number
See rating details on
machine
Intended Use
Introduction
Delivered Items
Operating Controls
For Your Safety
Warning! Switch off, remove plug from mains
before adjusting, cleaning or if cable is cut,
damaged or entangled.
The blades continue to rotate for a few sec-
onds after the machine is switched off.
Caution – do not touch rotating blades.
B
