Bosch Rotak 34 R User Manual

4 | English
F 016 L81 478 | (21.1.16) Bosch Power Tools
Intended Use
The garden product is intended for domestic lawn mowing.
Technical Data
Noise/Vibration Information
Measured sound values determined according to
2000/14/EC (1.60 m height, 1 m distance away).
Typically the A-weighted noise levels of the product are:
Sound pressure level 82.5 dB(A); sound power level
95 dB(A). Uncertainty K =1 dB.
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60335:
a
h
<2.5m/s
2
, K =1.5 m/s
2
.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical data” is in conformity with the fol-
lowing standards or standardization documents: EN 60335,
EN 50581 according to the provisions of the directives
2011/65/EU, 2014/30/EU, 2006/42/EC, 2000/14/EC.
2000/14/EC: Guaranteed sound power level 96 dB(A).
Conformity assessment procedure according to Annex VI.
Equipment category: 32
Notified body:
SRL, Sudbury, England, Nr. 1088
Technical file (2006/42/EC, 2000/14/EC) at:
Bosch Lawn and Garden Ltd., PT-HG/ENS-PA2,
Stowmarket, Suffolk IP14 1EY, England
Robert Bosch Power Tools GmbH
70538 Stuttgart, GERMANY
Stuttgart, 01.01.2017
Mounting and Operation
Wear protective gloves
Weight
Switching On
Switching Off
Symbol Meaning
Permitted action
Prohibited action
Accessories/Spare Parts
Symbol Meaning
Lawnmower Rotak 34 R
Rotak 340 R
Rotak 37 R
Rotak 370 R
Article number
3 600 HA6 1.. 3 600 HA6 2..
Rated power input
W 1300 1400
Blade width
cm 34 37
Height of cut
mm 20 – 70 20 – 70
Grassbox, capacity
l4040
Weight according to EPTA-Procedure 01:2014
kg 11.3 12.3
Protection class
/II /II
Serial number see type plate on the garden product
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your garden product. The trade names of the individual garden products may vary.
Starting cycles generate brief voltage drops. Interference with other equipment/machines may occur in case of unfavourable mains system conditions.
Malfunctions are not to be expected for system impedances below 0.36 ohm.
Henk Becker
Executive Vice President
Engineering
Helmut Heinzelmann
Head of Product Certification
PT/ETM9
Action Figure
Delivery Scope 1
Wheel Assembly 2
Handle Assembly 3
Snap together the Grassbox 4
Grassbox fitting/removing 4
Adjusting the Cutting Height 5
Starting 6
Stopping 6
Working Advice 6 – 7
Blade Maintenance 8
Selecting Accessories 9
OBJ_BUCH-2040-002.book Page 4 Thursday, January 21, 2016 11:33 AM

Bosch Rotak 34 R Specifications

General

Type	Push lawn mower
Torque (max)	20 N⋅m
Cutting width	340 mm
Product color	Black, Green
Uncertainty K	1.5 m/s²
Cutting system	Rotary blades
Number of speeds	6
Number of wheels	4 wheel(s)
Adjustable handle	Yes
Vibration emission	2.5 m/s²
Maximum cutting height	70 mm
Minimum cutting height	20 mm
Grass collecting volume	40 L
Power source	AC

Weight and Dimensions

Weight	11100 g
