Bosch Rotak 34 R User Manual

English | 5
Bosch Power Tools F 016 L81 478 | (21.1.16)
Troubleshooting
After-sales Service and Application
Service
www.bosch-garden.com
In all correspondence and spare parts orders, please always
include the 10-digit article number given on the type plate of
the garden product.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or arrange
the collection of a product in need of servicing or repair.
Tel. Service: (0344) 7360109
E-Mail: boschservicecentre@bosch.com
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: (01) 4666700
Fax: (01) 4666888
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: (01300) 307044
Fax: (01300) 307045
Inside New Zealand:
Phone: (0800) 543353
Fax: (0800) 428570
Outside AU and NZ:
Phone: +61 3 95415555
www.bosch.com.au
STOP
Problem Possible Cause Corrective Action
Motor refuses to start Power turned off Turn power on
Mains socket faulty Use another socket
Extension cable damaged Inspect cable, replace if damaged
Fuse faulty/blown Replace fuse
Grass too long Increase height of cut and tilt garden product
to reduce starting load
Motor protector has activated Allow motor to cool and increase height of cut
Machine functions
intermittently
Extension cable damaged Inspect cable, replace if damaged
Internal wiring of garden product damaged Contact Service Agent
Motor protector has activated Allow motor to cool and increase height of cut
Garden product leaves ragged
finish
and/or
Motor labours
Height of cut too low Increase height of cut
Cutting blade blunt Replace the blade
Possible clogging Check underneath the garden product and
clear out as necessary (always wear gardening
gloves)
Blade fitted upside down Refit blade correctly
Blade not rotating while garden
product switched on
Cutting blade obstructed Switch off garden product
Clear obstruction (always wear gardening
gloves)
Blade nut/bolt loose Tighten blade nut/bolt (17 Nm)
Excessive vibrations/noise Blade nut/bolt loose Tighten blade nut/bolt (17 Nm)
Cutting blade damaged Replace the blade
OBJ_BUCH-2040-002.book Page 5 Thursday, January 21, 2016 11:33 AM

Bosch Rotak 34 R Specifications

General

Type	Push lawn mower
Torque (max)	20 N⋅m
Cutting width	340 mm
Product color	Black, Green
Uncertainty K	1.5 m/s²
Cutting system	Rotary blades
Number of speeds	6
Number of wheels	4 wheel(s)
Adjustable handle	Yes
Vibration emission	2.5 m/s²
Maximum cutting height	70 mm
Minimum cutting height	20 mm
Grass collecting volume	40 L
Power source	AC

Weight and Dimensions

Weight	11100 g
