English | 11
Bosch Power Tools F 016 L70 761 | (25.5.11)
Equipment category: 32
Notified body:
SRL, Sudbury, England, Nr. 1088
Technical file at:
Bosch Lawn and Garden Ltd., PT-LG/EAE,
Stowmarket, Suffolk IP14 1EY, England
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
23.08.2010
Mounting and Operation
Troubleshooting
After-sales Service and Customer
Assistance
www.bosch-garden.com
In all correspondence and spare parts orders, please
always include the 10-digit article number given on the
type plate of the garden product.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: +44 (0844) 736 0109
Fax: +44 (0844) 736 0146
E-Mail: boschservicecentre@bosch.com
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: +353 (01) 4 66 67 00
Fax: +353 (01) 4 66 68 88
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: +61 (01300) 307 044
Fax: +61 (01300) 307 045
Inside New Zealand:
Phone: +64 (0800) 543 353
Fax: +64 (0800) 428 570
Outside AU and NZ:
Phone: +61 (03) 9541 5555
www.bosch.com.au
Republic of South Africa
Customer service
Hotline: +27 (011) 6 51 96 00
Gauteng – BSC Service Centre
35 Roper Street, New Centre
Johannesburg
Tel.: +27 (011) 4 93 93 75
Fax: +27 (011) 4 93 01 26
E-Mail: bsctools@icon.co.za
KZN – BSC Service Centre
Unit E, Almar Centre
143 Crompton Street
Pinetown
Tel.: +27 (031) 7 01 21 20
Fax: +27 (031) 7 01 24 46
E-Mail: bsc.dur@za.bosch.com
Western Cape – BSC Service Centre
Democracy Way, Prosperity Park
Milnerton
Tel.: +27 (021) 5 51 25 77
Fax: +27 (021) 5 51 32 23
E-Mail: bsc@zsd.co.za
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
Action Figure
Delivery Scope 1
Handle Assembly 2
Snap together the Grassbox 3
Grassbox fitting/removing 3
Adjusting the Cutting Height 4
Connecting the Extension Lead 5
Starting 5
Stopping 5
Working Advice 5
– 6
Blade Maintenance 7
Selecting Accessories 8
STOP
Problem Possible Cause Corrective Action
Motor refuses to
start
Power turned off Turn power on
Mains socket faulty Use another socket
Extension cable damaged Inspect cable, replace if damaged
Fuse faulty/blown Replace fuse
Grass too long Increase height of cut and tilt garden prod-
uct to reduce starting load
Motor protector has activated Allow motor to cool and increase height of
cut
Garden product
functions
intermittently
Extension cable damaged Inspect cable, replace if damaged
Internal wiring of garden product damaged Contact Service Agent
Motor protector has activated Allow motor to cool and increase height of
cut
Garden product
leaves ragged finish
and/or
Motor labours
Height of cut too low Increase height of cut
Cutting blade blunt Replace the blade
Possible clogging Check underneath the garden product and
clear out as necessary (always wear garden-
ing gloves)
Blade fitted upside down Refit blade correctly
Blade not rotating
while garden prod-
uct switched on
Cutting blade obstructed Switch off garden product
Clear obstruction (always wear gardening
gloves)
Blade nut/bolt loose Tighten blade nut/bolt (17 Nm)
Excessive vibra-
tions/noise
Blade nut/bolt loose Tighten blade nut/bolt (17 Nm)
Cutting blade damaged Replace the blade
OBJ_BUCH-1328-002.book Page 11 Wednesday, May 25, 2011 10:07 AM
