29
If the dishwasher came with a non-slotted toe panel (I) and toe panel
brackets (K) follow these instructions;otherwise skip to 27 now.
• Plug metal brackets (K) into openings on both sides of the base as
shown.
• Use screw (H) to mount metal brackets to the base as shown.
24
H
K
Attaching the Toe Panel
If your dishwasher came with a slotted toe panel (G) only, follow these
instructions; otherwise skip to 24 now.
Note: If using the slotted toe panel shown in 23 above, then metal mounting
brackets shown in 24 are not required.
• Position the slotted toe panel (G) on the dishwasher. Allow it to rest on
the floor.
• Attach using screws (H) as shown. Use only the supplied screws to
avoid damaging the dishwasher. The toe panel should be flush with the
floor. The installation is complete!
23
G
H
